The Epoxy Acrylate, Hammer In Capsules are suitable for use in solid concrete and natural stone.
They can be used with reinforcing bar or threaded rods and can achieve high loads by using two capsules at double embedment depth.
Product Information
The Epoxy Acrylate. Hammer in capsules are suitable for use in solid concrete and some natural stone. They can be used with reinforcing bar or threaded rods and can achieve high loads by using
2 capsules at double embedment depth.
Features
Expansion Free
High Loads
Increased Embedment Depth
Rapid Installation
|
|
|
Rebar |
Rebar |
Rebar |
Rebar |
Threaded Bar |
Threaded Bar |
Threaded Bar |
Threaded Bar |
| Part Number |
Capsule Dia. |
Capsule Length |
Nominal Dia. |
Drill Dia. |
Hole Depth Single |
Hole Depth Double |
Nominal Dia. |
Drill Dia. |
Hole Depth Single |
Hole Depth Double |
| JCAPHM08 |
9mm |
80mm |
8mm |
10mm |
80mm |
160mm |
8mm |
10mm |
80mm |
160mm |
| JCAPHM10 |
11mm |
80mm |
10mm |
13mm |
100mm |
200mm |
10mm |
12mm |
100mm |
200mm |
| JCAPHM12 |
13mm |
95mm |
12mm |
15mm |
120mm |
240mm |
12mm |
14mm |
120mm |
240mm |
| JCAPHM16 |
17mm |
95mm |
16mm |
20mm |
160mm |
320mm |
16mm |
18mm |
125mm |
250mm |
| JCAPHM20 |
22mm |
175mm |
20mm |
25mm |
200mm |
400mm |
20mm |
25mm |
200mm |
400mm |
| JCAPHM24 |
24mm |
210mm |
25mm |
30mm |
250mm |
500mm |
24mm |
28mm |
240mm |
480mm |
| JCAPHM30 |
33mm |
265mm |
32mm |
38mm |
320mm |
640mm |
30mm |
35mm |
300mm |
600mm |
Setting Times
| Base Material Temp. |
Cure TIme Dry Concrete |
Cure Time Wet Concrete |
| >20°C |
60 Minutes |
120 Minutes |
| 10 to 20°C |
2 Hours |
4 Hours |
| 0 to 10°C |
5 Hours |
10 Hours |
| -5 to 0°C |
10 Hours |
|
